EXPLODED VIEW - CRAFTSMAN 2000 PSI PRESSURE WASHER 1054-0
DRAWING NO. - B2793
riEM
PAFTTNO.
QTY.
DESCRIPnON
riEM
PART NO.
QTY.
DESCRIPTION
1
EB2789
1
BASE, HSPW
26
A1041
1
HLTER, Chemical Hose
2
B2393
1
ENGINE, Honda 5HP
27
A1408
1
CAP, Garden Hose Inlet
3
A1803C*
1
PUMP, Medium Frame
29
B1288
1
TAG, Breather Cap
4
EB2534
1
HANDLE
30
21782
1
QUICK DISCONNECT,
5
22129
8
LCXKWASHER, M8
Female
6
52858
2
NUT. M8 Locking
31
21781
1
QUICK DISCONNECT,
Range
Male
7
51731
2
HHCS, M8x50
32
50190
2
WASHER, M8 Rat
8
27007
2
MOUNT, Rubber Foot
33
48031G
1
CLAMP, Hose 3^16"
9
B2142
2
WHEEL, 2"
X
9" Black
34
B2759
1
HOOK, Square Neck
Mag
1/4"-20
10
75402
2
PUSHNUT, 1/2"
35
97054
1
TAG, Pressure Adjust
11
B2168
1
HANGER, Hose
36
97100
1
CAP, High Pressure
12
B1460
3
CAP, Vinyl
37
B1969
1
HOSE, 1/4"
X
25’
13
B1779
2
COVER, Hinge
38
95529
1
TURBO, Nozzle
14
B2347
2
CAP, End
39
B2370
1
GUN, High Pressure
15
46476
2
CAPLUG
40
95587E
1
NOZZLE, Adjustable
16
31669
1
BOLT. 1/4"-20x1-3^4"
41
97123
1
WAND, Extension
Carriage
43
21217
4
MOUNT, Vibration
17
B2071
2
NUT, 1/4"-20 Locking
44
97566
1
TAG, Nozzle
Range
45
45771
8
NUT, M8-1.25 Hex
18
92235
1
GROMMET, Turbo
46
B2517
1
DECAL Recoil Honda
No
2
zle
47
96382
1
OIL Engine SAE 30
19
B1631A
1
BILLBOARD
48
B1849
1
M/\NUAL Owners
20
B1851
1
DECAL, Craftsman
49
B2730
1
KIT, O-Ring
2000 PSI
Maintenance
21
B2796
1
DEC/VL, Instructions
50
97009
1
KIT, Nozzle Cleaning
22
91373
1
DEC/y_, Data
51
B3095
1
DECAL 5.0 HP
23
79552
1
OVERLAMINATE
24
96307
1
DECAL 1-800#
25
A1040A
1
HOSE, Chemical
* Complete pump assembly is not available. Reference pump exploded view for individual parts.
