CARBURETOR
----- Q
Ref No.
Descriotion
Qty.
Part No.
1
Gasket Set
1
16010-883-015
2
Float Set
1
16013-ZL1-003
3
Chamber Set, Float
1
16015-2L8-003
4
Screw Set
1
16016-ZG0-W00
5
Screw Set, Drain
1
16024-124-760
6
Screw Set B
1
16028-ZE0-005
7
Screw Set
1
16029-ZG0-901
8
Carburetor Assy. (BB61B B)
1
16100-ZL8-801
9
Valve Comp., Float
1
16155-ZL8-003
10
Nozzle, Main
1
16166-ZL8-003
11
Insulator, Carburetor
1
16211-ZL8-000
12
Gasket, Insulator
1
16212-ZL8-000
13
Gasket, Carburetor
2
16221-883-800
14
Gasket, Carburetor (Choke side)
1
16288-ZL8-000
15
Guide Comp., Air
1
19650-ZL8-000
16
Screw, Pan (5x6)
1
93500-05006-1H
17
Clip, Tube (B6.5)
1
95002-02650
18
Bulk Hose, Vinyl (4x7x8000)
(4x7x150)
1
95003-07008-60M
19
Jet, Main (#60)
1
99101-124-0600
Jet, Main (#62)
(1)
99101-124-0620
Jet, Main (#65)
1
99101-124-0650
22
