FEATURES
PRODUCT SPECIFICATIONS
Depth of Cut (Fixed Base & D-handle Base) 1-1/2 in­
Depth of Plunge (Piunge Base)......................................................................................................................................................... 2 in.
Collet..................................................................................................................................................................................................... 1/4 in­
Horsepower.............................................................................................................................................................................................2
Rating............................................................................................................................ 120 Volts, 60 Hz, AC only, 9.5 Amperes
No Load Speed....................................................................................................................................................................25,000/min
Power Cord............................................................................................................................................................................................10 ft-
Net Weight........................................................................................................................................................................... 5 lbs. 6 oz.
KNOW YOUR ROUTER
Before attempting to use this product, familiarize
yourself with all operating features and safety rules.
Your new router motor is equipped with the following
features. S e e F ig u re 1 .
SWITCH
The router has a conveniently located toggle switch.
SPINDLE LOCK
The spindle lock secures the spindle while you make
adjustments and acts as a retainer to keep the router
body from coming out of the base.
MOTOR
HOUSING
GOLD SPINDLE
LOCK BUTTON
SWITCH
Fig. 1
