WAN port
(10BaseT)

Connect the ADSL or Cable Modem here. If your modem came
with a cable, use the supplied cable. Otherwise, use a standard LAN
cable.

WAN Port LED

Flashing - data is being transmitted or received via the WAN port.

OFF - no data is being transferred.

Reset Button

When pressed and released, the Broadband Router will reboot
(restart).

Power port (12V)

Connect the supplied power adapter here.

DIP Switches

DIP Switch Setting Description

1=off
2=off

Normal Operation

1=off
2=on

DHCP Server function disabled.

1=on
2=off

Used to restore Default IP Address
and clear Password (See below)

1=on
2=on

Normal Operation.

Restore Default IP Address and Clear Password

If the Broadband Router's IP Address or password is lost, the following procedure can be used
to recover from this situation.
1. Turn the power to the Broadband Router OFF.
2. Set DIP switch 1 ON.
3. Turn the power to the Broadband Router ON.
4. Operate DIP switch 1 in the following sequence (you have 15 seconds to complete the

sequence):
• OFF
• ON
• OFF

5. The Broadband Router will now reset, and the Yellow Status LED flash. The following

changes will have been made. (Other configuration data is unchanged.)
• IP Address set to its default value of 192.168.0.1
• Network Mask set to 255.255.255.0
• DHCP Server is enabled, and will allocate IP Addresses in the range 192.168.0.2 to

192.168.0.51.

• The password cleared (no password).

6. You can now connect to the Broadband Router and make any configuration changes

required.
