ENGINE PARTS
CRAFTSMAN 2700 PSI HIGH PRESSURE WASHER 919.762700 ENGINE NUMBER 138432>0035>A1
REF. PART REF. PART REF. PART
NO, NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
16 715426 Crankshaft 25 715456 Piston Assy. 27 710040 Lock-Piston Pin
Used on Type No{s). (Standard) 28 715455 Pin-Piston Std.
0035, 0084 715457 Piston Assy. 29 715427 Rod-Connecting
(.010” O.S.) (Standard)
715448 Piston Assy. 715502 Rod-Connecting
(.020" O.S.) (.020” Undersize)
26 715452 Ring Set 32 710041 Screw-Connecting
(Standard) Rod
715453 Ring Set 46 715451 Grear-Cam
(.010" O.S.) 718A 710616 Pin-Compression
715454 Ring Set
(.010” O.S.) 1051 710039 Ring-Retaining
#!nduded in Gasket Set-Part No. 715482
★ Included inValve Overiiau! Kit-Part No. 715483
Ainciuded in Carburetor Kit-Part No. 715484
★ Included in Gasket Gasket Set -Part No. 715485
22
