REPAIR PARTS LIS'
J
MODEL #486.24628 BRUSH GUARD
REF QTY PART NO. DESCRIPTION REF QTY PART NO. DESCRIPTION
1 1 421265 Brush Guard Assembly 10 4 43082 Lock Nut, 3/8"
2 1 66696 Latch 11 2 1509-90 Hex Bolt, 1/4-20 X 1-1/4"
3 2 26729 Frame Brace 12 4 46978 Hex Nut (SIMS), 1/4"
4 4 43350 Carriage Bolt, 3/8-16 x 1" 13 2 42117 Spring
5 4 44072 Whiziock Nut, 3/8" 14 1 422754 Shroud
6 2 43001 Hex Bolt, 3/8-16x1" 15 2 422752 End Cap
7 2 43070 Washer, 3/8" 16 2 48840 Screw, 1/4-20 x 1/2"
8 2 48106 Shoulder Bolt, 3/8-16 1 42187 Owners Manual
9 2 R19171616 Washer, .5312x1 x .0598"
Call 1 -866-576-8388 for missing parts or assembly help
DO NOT RETURN TO STORE
