Craftsman 247.27022 - Manual (Page 43)

Briggs & Stratton Engine 212907-0272 for Craftsman Riding Mower Model 247.27022
Key No. Part No. Description Key No. Part No. Description
1 697377 Cylinder Assembly 108 690464 Choke Valve
2 399265 Kit: Bushing/ Seal (Magneto side) 108A 691227 Choke Valve
3 391086 Oil Sea! (Magneto side) 117 697490 Jet; Main (Standard)
4 697106 Sump: Engine 118 697492 Jet: Main (High Altitude)
5 697396 Head: Cylinder 121 697535 Kit: Carburetor Overhaul
7 273280 Gasket: Cylinder Head 125 697432 Carburetor
9 697109 Gasket: Breather 127 694524 Plug: Welch
10 697157 Screw (Breather Assembly) 130 690468 Throttle Valve
11 697113 Tube: Breather 131 697452 Kit: Throttle Shaft
12 697110 Crankcase Gasket (.015” Thick) 133 494381 Float: Carburetor
13 690360 Screw (Cylinder Head): 2-5/8” Lg. 137 281165 Gasket: Float Bowl
15 690946 Plug: Oil Drain 141 495097 Choke Shaft Kit
16 697390 Crankshaft 141A 699027 Kit: Choke Shaft (Choke-a-matic)
20 690947 Oil Seal (PTO Side) 142 697491 Carburetor Nozzle (Standard)
22 692125 Screw (Crankcase Cover/Sump) 143 697492 Nozzle; carburetor (High Altitude)
23 698281 Flywheel 146 691639 Key: Timing
24 222698 Key: Flywheel 186 698174 Hose Connector
25 698371 Piston Assembly (Standard) 187 697098 Fuel Line
698376 Piston Assembly (.010” Oversize) 188 691693 Screw (Control Bracket)
698377 Piston Assembly (.020” Oversize) 192 691986 Adjuster: Rocker Arm
698378 Piston Assembly (.030” Oversize) 202 691841 Link; Mechanical Governor
26 698375 Ring Set (Standard) 209 692208 Spring: Governor
698376 Ring Set (.010” Oversize) 216 691840 Link: Choke
698377 Ring Set (.020“ Oversize) 222 694042 Bracket; Control
698378 Ring Set (.030” Oversize) 227 691374 Lever; Governor Control
27 698469 Lock: Piston Pin 232 691842 Spring: Governor Link
28 697099 Pin: Piston (Standard) 238 691843 Valve Cap
29 697364 Connecting Rod (Standard) 240 298090 Fuel Filter
32 692852 Screw (Connecting Rod) 276 692255 Washer: Sealing
33 495856 Exhaust Valve 304 496832 Blower Housing
34 495857 intake Valve 305 697102 Screw (Blower Housing)
35 691279 Valve Spring: Intake 305A 697103 Screw (Blower Housing)
36 691279 Valve Spring; Exhaust 306 697359 Cylinder Shield
37 697352 Flywheel Guard 307 691003 Screw: Cylinder Shield
40 691752 Valve Retainer 309 693551 Starter Motor
43 691968 Govemor/Oil Slinger 310 690323 Bolt; Starter Motor
45 690564 Tappet: Valve 311 497608 Brush Set
46 699016 Camshaft 333 492341 Magneto Armature
50 697361 intake Manifold 334 691061 Screw; Magneto Armature
51 692137 intake Gasket 337 491055 Spark Plug
53 690227 Stud (Carburetor) 356 697397 Wire: Stop
54 691148 Screw (Intake Manifold) 358 697151 Gasket Set; Engine
73 697384 Screen: Rotating 363 19203 Flywheel Puller
74 697897 Screw: Rotating Screen 383 89838 Wrench: Spark Plug
75 690582 Washer (Flywheel) 404 691691 Washer; Governor Crank
78 691003 Screw (Flywheel Guard) 431 698937 Elbow: Intake
93 690602 Bushing; Throttle Shaft 462 691261 Washer (Starter Cable)
94 498030 Kit; idle Mixture 474 696578 Alternator
95 691636 Screw: Throttle Valve 503 691532 Strap: Starter
98 495800 Kit: Idle Speed 505 691251 Nut (Governor Control Lever)
104 690525 Pin: Float Hinge 510 693699 Drive; Starter
105 231855 Valve: Float Needle 513 692024 Drive Clutch
106 690577 Seat: inlet 523 697086 Dipstick
