Installation
External Equipment Connections Continued
1 A V Sf'i ir:':.-
Connections
Connect the audio/video output jacks on the
external A/V equipment to the corresponding
input jacks on the TV. When connecting the
TV to external A./V equipment^ match the jack
coiors (Video = yeilow Audio Left = white
and Audio Right = red).
Viewing Setup
1. Turn on the external A/V equipment.
2. Use the INPUT button on the remote con­
trol to select Video.
3. Operate the corresponding external equip­
ment. Refer to external equipment operat­
ing guide.
r » ■: - : ®
0 6 6 0 0 0 3 © ©
^ -f' - i...
External
Equipment
rS
t- Camcorder
Video Game
set
1 ; V 1 ' ; . S i - : : i | ,
Connections
1 . Connect the DVD video outputs to the COMPONENT (Y, PB, PR) jacks and connect the DVD audio
outputs to the AUDIO jacks.
2. If your DVD only has an S-Video output jack, connect this to the S-VIDEO input on the TV and con­
nect the DVD audio outputs to the AUDIO INPUT Jacks on the TV.
NOTE: If your DVD player does not have component video output, use S-Video.
Viewing Setup
1 . Turn on the DVD player, insert a DVD.
2. Use the INPUT button on the remote control to select
Component.
3. Refer to the DVD player's manual for operating instruc­
tions. (If connected to S-VIDEO on rear panel, select the
Video external input source.)
Component I n p u t ports
To get better picture quality connect a DVD player to
the component input ports as shown below.
Component ports
of the TV
Y P b . Pr,
Video output ports
of DVD player
Y Pb Pr
Y ■■■
Y Cb Cr
Y P b P-
i.',—..................
© 0 0 0 0 0 0
®
I il A A A A "«»“O
II
' ' "" lifL
lli
T T
QL.iA'i ro f.'i
DVD
Model Signal Qsnijonent RGB-DTV
15LC1R* 480i/480p Yes Yes
20LC1 R* 480i/480p Yes No
14
