With a cable box
(Rear of TV)
Note
• To connect a monaural VCR, connect the audio output of the
VCR to AUDIO-L (mono) of VIDEO 1 IN on the TV.
To an S video equipped VCR with a cable box
(Rear of TV)
m
OUT
line
OUT
0
Cable box
Cable
=cin]«~N
.♦1
- -< 1—IN________ —1.
i
OUT
Splitter
YC-15V/30V
(not supplied)
-L
S-VIDEO
AUDIO-L (white)
AUDIO-R (red)
RK-74A
(not supplied)
Note
• Video signals are composed of Y (luminance) and C (chroma)
signals. The S connection sends the two signals separately
preventing degradation, and gives better picture quality
compared to conventional connection.
Getting Started
