Using Your Display
Preset and user modes
The Multiscan CPD-120VS/220VS display has factory preset modes for
the 10 most popular industry standards for true “plug and play"
capability.
For less common modes, its Digital Multiscan Technology will perform
all of the complex adjustments necessary to ensure a high quality picture
for any timing between 30 and 70 kHz.
NO. Resplution
(dots
X
lines)
Horizontal
Frequency
Vertical
Frequency
1 640 X 400 31,5 kHz 70 Hz
2 640 X 480 31.5 kHz 60 Hz
3 640
X
480 43.3 kHz 85 Hz
4 800
X
600 37.9 kHz 60 Hz
5 800 X 600 46.9 kHz 75 Hz
6 1024
X
768 60.0 kHz 75 Hz
7 1024
X
768 68.7 kHz 85 Hz
8 1152 X 864 44.8 kHz 47 Hz (95 Hz interlace)
9 1152
X
864 54.8 kHz 60 Hz
10 1280 X 1024 64.0 kHz 60 Hz
\/Note for Windows* 95 users
Install the new model information of the Sony computer display from "Windows 95 Monitor
Information disk" into your PC. (To install the file, refer to the attached "About the Windows
95 Monitor Infomration Disk".)
This display complies with "VESA DDC," the standards of Plug & Play. If your PC/graphic board
complies with DDC, select "Plug & Play Display (VESA DDC)" or this display's model name
(CPD-120VS/220VS) as "Display type" from "Control Panel" on Windows 95. Some PC/
graphic boards do not comply with DDC. Even if they comply with DDC, that may have some
problems on conneding this display. In this case, select this display's model name (CPD-
120VS/220VS) as "Display type" on Windows 9^
Windows® is a registered trademark of Microsoft Corporation in the United States and other
countries.
s /Note on recommended horizontal timing conditions
Horizontal sync width should be more than 1.0 psec.
Horizontal blanking width should be more than 3.6 psec.
Continued to the next page
Using Your Display 13
