2.5 Battery Capacity:
Standard Battery
Extended Battery
10OOmAh typical
1450mAh typical
Ll-ion QN-CD5BPS
Li-ion QN-CD5BPE
The phone can be charged even during making phone calls.
However, the shortest charging time will be reached when the phone is switched off.
As the charging circuit is integrated in the battery pack, the phone cannot be powered up by the charger without the
battery pack being attached.
2.6 Accessory interface
The table explains what kind of pins the phone supplies to the different accessories.
Pins
GND
18
Charge
1/2
ACC_
power
3
Audio
IN
14
Audio
Out
13
ACC
ID
11
ACC
Detect
6
TX
(OUT)
9
RX
(IN)
10
AGND
12
Charger
V
V
CLC
V
V
Desktop charger
V
V
Head set
V
V
V
V
V
a
/
V
HFK
V
V
V
V
a
/
V
V
PCMCIA
V
V
a
/
V
V
V
EasyCom
V
a
/
a
/
V
V
V
Connector layout
18 2
