PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
11
NO T Picture d
… 1 DO O R M AG NET
… 1 CAST ER PIN
… 1 HARDW ARE PACK
… 1 ASSEM BLY M ANUAL, ENG LISH
… 1 ASSEM BLY M ANUAL, FRENCH
… 1 CLEANING T O O L
Key Qty Description
A 1 TOP LID, OUTER
B 1 INNER INSERT F/ TOP LID
C 1 HANDLE F/ TOP LID
D 1 LOGO PLATE
E 2 RUBBER BUMPER, RECTANGLE, F/ TOP LID
F 1 FIREBOX
G 2 COOKING GRATE
H 2 COOKING GRATE, TRAY
I 1 WARMING RACK
J 1 FLAME CARRYOVER TUBE W/ COTTER PIN
K 2 MAIN BURNER, F/ FIREBOX
L 2 FLAME TAMER
M 2 ELECTRODE W/ WIRE/COLLECTOR, F/ MAIN
BURNER
N 2 SIDE SHELF, FIXED
O 2 SIDE SHELF, FOLDING
P 1 FASCIA, F/ LEFT SIDE SHELF
Q 1 FASCIA, F/ RIGHT SIDE SHELF
R 1 MAIN CONTROL PANEL
S 2 TEMPERATURE GAUGE, UFC MOUNTED
T 1 HOSE VALVE REGULATOR ASSY
U 1 MATCH HOLDER
V 2 BEZEL, F/ CONTROL KNOB
W 2 CONTROL KNOB
X 1 CART UPPER BACK PANEL
Y 1 LEFT RAIL, F/ GREASE TRAY
Z 1 RIGHT RAIL, F/ GREASE TRAY
AA 1 GREASE TRAY
BB 1 FRONT DOOR BRACE
CC 1 ELECTRONIC IGNITION MODULE
DD 1 BUTTON, F/ ELECTRONIC IGNITION MODULE
EE 1 IGNITER SWITCH MODULE
FF 1 DOOR, NO HANDLE
GG 1 DOOR HANDLE
HH 1 CART LEFT SIDE PANEL
II 1 CART RIGHT SIDE PANEL
JJ 1 BOTTOM SHELF
KK 1 TANK SCREW, F/ BOTTOM SHELF
LL 2 CASTER, LOCKING
MM 2 CASTER, FIXED
NN 1 HARDWARE F/ TOP LID ASSEMBLY
OO 2 RUBBER BUMPER, LID
