PTS - 31
ZTS 6000 - Model No. 107.289930
Kohler Engine Parts
-
SV735-0018
HEAD/VALVE/BREATHER - Group 4
1 32 096 06-S KIT, BREATHER VALVE COVER
(INCLUDES 2 [QTY 1])
2 24 153 30-S O-RING, VALVE COVER
3 M-651030-S SCREW, FLG M6X1.0X30
5 12 755 03-S KIT, RETAINER
6 12 173 01-S CAP, VALVE SPRING
7 24 089 02-S SPRING, VALVE
8 235011-S RETAINER, SPRING
9 66 032 05-S SEAL, VALVE STEM
10 24 017 01-S VALVE, INTAKE (STD)
11 24 016 01-S VALVE, EXHAUST (STD)
12 32 326 06-S KIT, BREATHER HOSE
(INCLUDES 13)
13 25 237 14-S CLAMP, HOSE 1/2"
14 32 081 02-S KIT, BREATHER HOUSING
(INCLUDES 15,16)
15 M-547050-S NUT, LOCK M5X.8
16 32 468 01-S WASHER, SEALING
17 32 072 03-S STUD, BREATHER COVER
18 32 019 02-S TAPPET
20 32 841 01-S KIT, CYLINDER HEAD GASKET
(INCLUDES 26[QTY 4]
& 24 041 49-S, 24 153 27-S)
26 12 086 16-S SCREW, FLG M10X1.5X90
28 24 755 141-S KIT, BREATHER VALVE COVER
(INCLUDES 2 [QTY 1], 3 [QTY 4])
29 25 445 01-S STRAP, LIFTING
30 M-645016-S SCREW, FLG THD FRM M6X1.0X16
31 32 096 04-S KIT, BREATHER COVER
(INCLUDES 32)
33 32 050 01-S FILTER, BREATHER
34 32 318 13-S KIT, #1 CYLINDER HEAD ASSY
(INCLUDES EXHAUST
MOUNTING HARDWARE)
35 32 318 14-S KIT, #2 CYLINDER HEAD ASSY
(INCLUDES EXHAUST
MOUNTING HARDWARE)
36 32 146 09-S PLATE, GUIDE
37 32 072 04-S STUD, ROCKER
38 32 186 03-S ARM, ROCKER
39 32 100 05-S HEX NUT ASSEMBLY
(INCLUDES 39)
40 25 086 168-S SCREW, SET
41 25 599 01-S PIVOT, ROCKER ARM
42 32 411 04-S ROD, PUSH
43 32 326 07-S KIT, FUEL PUMP HOSE W/CLAMP
(INCLUDES 44)
44 25 237 01-S CLAMP, HOSE
NOT ILLUSTRATED
32 755 03-S KIT, CYLINDER HEAD HARDWARE
(SERVICES 1 HEAD. QUANTITIES
LISTED ARE FOR BOTH HEADS)
(INCLUDES 5-11,19,22,25,34)
24 041 49-S GASKET, EXHAUST
24 153 27-S O-RING, INTAKE PORT
REF. PART DESCRIPTION REF. PART DESCRIPTION
