Ref. Part No. Description Qty. Qty.
1 71119A Label 1 1
2 21074A Handle Front 1 1
3 10687A Module 1 1
4 80290A Screw, 10-32 x 3 /
8
4 4
5 80291A Washer, #10 1 1
6 21075A Handle Back 1 1
7 80284A Screw, 10-32 x 3 /
4
6 6
8 61373A Handle Tube 1 1
9 10304A Adaptor - 1
10 85815A Screw, 5 /
16
x 1¼ - 1
11 Ref.* Bushing (Equipped with 40789A) 1 1
12 40789A* Cord Interconnect 1 1
13 40919A Cord, Power 1 1
14 30407B Hose, Squeegee - 1
15 980648 Washer, ½ 2 2
16 80295A Washer, Bowed 2 2
17 53833A Pin, ½ 2 2
18 61725A Axle 1 1
19 61832A Shield, Inner - 1
20 30725A Skirt - 1
21 10242A Pad Driver 1 1
NI 460215 Hard Plate (Option 1) 1 1
22 30381A Bumper 1 1
23 80294A Screw, 5 /
16
4 -
80305A Screw, 5 /
16
x 2 - 4
24 67890A Spacer, 7 /
8
x 9 /
16
x 5 /
16
- 4
25 61826A Shield (with connector) - 1
61715A Shield 1 -
26 21088A Main Frame 1 1
27 53650A Motor 1 1
28 70499A Label 1 1
29 39857A Wheel 2 2
30 80292A Screw, ¼-20 x 1 2 2
31 56057675 Grip Handle 1 1
32 53662A Pin, ¼ 1 1
33 461404 Cam, Locking 1 1
34 441301 Bolt, Locking Cam 1 1
35 980341 Washer 1 1
36 50781A Clamp 1 1
37 920342 Nut, 3 /
8
1 1
38 61716A Cover 1 1
39 71120A Label 1 1
40 920110 Nut, 5 /
16
- 1
RS-16, RS-16 DC
Assembly Drawing Parts List 1/06
