24
ARX8570z
DSP Operations
DSP control function
If the DSP (DPH7500z), sold separately, is con-
nected to this unit using the CeNET cable, all
the functions of the DSP can be controlled.
DSP functions
There are 2 modes available in DPH7500z, easy
mode and professional mode. Choose one of
them and adjust the sound field and the sound
quality.
• Functions common to each mode:
Spectrum analyzer display, auto loudness, etc.
• Easy mode:
Adjustment using the graphic equalizer function
and the DSP function.
• Professional mode:
Adjustment using the space equalizer function
and the parametric equalizer function.
∗
When the easy mode is selected, adjustment for
the professional mode cannot be made. On the
contrary, when the professional mode is selected,
adjustment for the easy mode cannot be made.
∗
For details on functions of each mode, refer to
the owner’s manual supplied with the
DPH7500z.
∗
Hereafter the graphic equalizer is referred to as a
G.EQ., the space equalizer referred to as S.EQ.
and the parametric equalizer referred to as P.EQ.
Operations common to each mode
Enjoying a spectrum analyzer
This unit can display the spectrum analyzer.
There are 8 spectrum analyzer patterns.
1. Press DISP button
0
to select the spectrum
analyzer display.
2. Each time you press and hold DISP button
0
for 1 second or longer, the spectrum ana-
lyzer patterns are switched.
Setting the sensitivity of the spec-
trum analyzer
∗
The factory default setting is “MID”.
1. Press and hold ADJ button
4
for 1 second or
longer to switch to the adjustment selection
display.
2. Press the right or left side of SEARCH button
$
to select “ANA SENS”.
3. Press ENT button
2
.
4. Turn the Rotary knob
%
clockwise or coun-
terclockwise to set the sensitivity of the spec-
trum analyzer.
You can choose one of “LOW”, “MID-LOW”,
“MID”, “MID-HIGH” or “HIGH” for the sensi-
tivity of the spectrum analyzer.
5. Pressing ENT button
2
returns to the adjust-
ment selection display.
6. Press ADJ button
4
to return to the previous
mode.
Output adjustment of auto loudness,
subwoofer and playback band
1. Press and hold ADJ button
4
for 1 second or
longer to switch to the adjustment selection
display.
2. Press the right or left side of SEARCH button
$
to select “SOUND”.
3. Press ENT button
2
.
4. Press the right or left side of SEARCH button
$
to select the adjustment item.
There are “A.LD LEVEL”, “WOOFER OUT”,
“WOOFER LPF”, “HPF” and “TEST TONE”
available for the adjustment items.
∗
For details on each adjustment item, refer to the
owner’s manual supplied with the DPH7500z.
5. Turn the Rotary knob
%
clockwise or coun-
terclockwise to make the adjustment.
6. Pressing ENT button
2
returns to the adjust-
ment selection display.
7. Press ADJ button
4
to return to the previous
mode.
Selecting easy mode or professional
mode
∗
The factory default setting is “EASY”.
1. Press and hold ADJ button
4
for 1 second or
longer to switch to the adjustment selection
display.
2. Press the right or left side of SEARCH button
$
to select “DSP/EQ SEL”.
3. Press ENT button
2
.
4. Turn the Rotary knob
%
clockwise or coun-
terclockwise to set the mode to “EASY” or
“PRO”.
5. Pressing ENT button
2
returns to the adjust-
ment selection display.
6. Press ADJ button
4
to return to the previous
mode.
