In use, the CGA end fitting on the Fill/Vent Tee Assembly couples to the fill connection
to be filled. The Relief Valve vents pressure over 350 psig (24-bar/2413 kPa) that builds
up in the fill line due to trapped liquid. The Dump Valve is used to allow the operator to
blow-down in the receiving container during a pump fill, or to relieve residual pressure
from expanding liquid trapped before disconnecting the fill line.
Fill kits are available with different combinations of hose length. The following chart
identifies the available transfer hoses and the Fill/Vent Tee assemblies that are appro-
priate for use with the XL-160/XL-180.
Transfer Hoses & FILL/VENT Tee Assemblies
The Fill/Vent Tee connects to a transfer hose to complete a fill line kit. Each assembly
includes a 3/8-in. pipe connector to CGA fitting with a 350-psig (24-bar/2413-kPa) relief
valve, and a ball-type dump valve.
Description
Cylinder
Connections
End
Fittings
Part
Number
Hose, 4 ft. (1.2 m) SS
LIQUID or VENT valve
CGA 295 to 3/8 in NPT
1700-9C65
Hose, 6 ft. (1.8 m) SS
LIQUID or VENT valve
CGA 295 to 3/8 in NPT
1600-9C66
Fill/Vent Tee Assemb.
LIQUID or VENT valve
CGA 295
GL50-8C60
