7
Digital (Enhanced) Overhead Stirrer
Power switch /Overload
protection light
Power/Overload
Green/Red LED display light.
LED light shows green when
switch on, LED light shows
red when starts overload
protection. When the torque
reaches limited value, overload
protection function will be
started. At the same time
overload protection light
flashes, while the system stops
running.
Drill chuck Can be held stirring impellers.
Power switch I/O
S w i t c h O N o r O F F t h e
instrument.
Table 2
• Place the overhead stirrer in safe and stable surface and
connect power cable.
• Switch ON instrument.
• The instrument begins self-checking.
• When initialization is over, displays“set”, at the same
time the area of value setting/display flashes that indicate
can be set speed value.
• Rotate speed control button to set stirring speed.
• LCD display no longer flashes when press speed button,
“
set”disappear, the stirring function starts.
• Press speed button again, LCD display flashes,“set”
display, the stirring function close.
6.2 Display
Figure 4
Display Descriptions
Set
Display when set target speed
value.
PC
Display when using external
probe.
Err
Display in case of error
happening.
Value set/display area
When Set display, this area
shows setting value; When
Set disappears, this area
shows running value.
Table 3
