Instruction Manual – D-160 Disperser&Homogenizer 5/ 9
must press the black button to lock it
Put the shaft tube onto the axle and screw clockwise onto the housing!
Press the black locking button and screw it fully onto the drive!
When assembling the dispersing tool, always make sure that the PTFE
bearing is fixed correctly and cooled by the working medium. Otherwise,
it may cause serious defects to the whole dispersing tool.
Examine the PTFE bearings regularly. Treat the dispersing tools carefully
as they are the hearts of your dispersing unit. In particular the axle reacts very sensitive
to impacts.
Cleaning

Immediately after finishing work with the apparatus, the dispersing element
must be cleaned so that substance residues do not stick to the threads.

Small bacterial cultures can form in the small grooves, and this will create
difficulties.
For this reason, and to clean the dispersing tool effectively, it should be run in a solvent
