Instruction Manual – D-160 Disperser&Homogenizer 3/ 9

When cleaning, remove the power cord from the power source.

Never touch the spinning rotor, or shaft, or motor side coupling parts.

Do not operate if damaged in any manner. Return unit to our service centre for
examination and repair.

Switch off the unit before changing the dispersing element.

Only suitable dispersing shafts from Scilogex must be used.

The ventilation slots of the drive must not be obstructed.

Never let the aggregate touch the bottom of the vessel.
Unpacking the Instrument
Please unpack the instrument carefully and inspect the unit, the tools and the stand (if
this has been ordered) for damage. It is important that any damage during transport is
noted at the time of unpacking. In certain cases it may be necessary to follow up with
the forwarder.
A typical delivery includes:

D-160 drive

One or more dispersing element according to your order

One small H stand with clamp (if stand has been ordered)

Operating instructions
Proper Use of the D-160
The voltage on the name plate must match the supplied voltage. If it does
not, do not operate the instrument.
Make sure that the unit is switched off when connecting or disconnecting
the dispersing shaft into the drive.
Insert the axle/rotor of the dispersing element completely into the drive coupling and
tighten the screw cap by holding the rotor axle of the motor. Then screw the stator/shaft
tube onto the motor flange directly.
To remove the dispersing element from the flange, remove the stator/shaft tube from the
drive. Hold the rotor axle of the motor to untighten the screw cap and remove the axle
rotor.
