Qmark High Velocity Electric Heated - Manual (Page 2)

High Velocity Series Specifications and Performance
NUMBER AIR DELIVERY @ NOZZLE OUTLET APPROX.
MODEL NOZZLE Volts Heater # MOTORS @ OF CONTROL MAX VEL AVG VEL AIRFLOW SHIPPING
NUMBER WIDTH (IN) AC Watts BTU/HR HP CABINETS VOLTAGE (FPM) (FPM) (CFM) WEIGHT (LBS)
1/2 HP Models
E42081#00HE 42 # 8000 27,320 1 @ 1 1 24 5250 3990 3770 109
E48081#00HE 48 # 8000 27,320 1 @ 1 1 24 5250 3890 4200 116
E60081#00HE 60 # 8000 27,320 1 @ 1 1 24 5250 3675 4960 132
E72162#00HE 72 # 16000 54,640 2 @ 1 2 24 5250 4200 6800 197
E84162#00HE 84 # 16000 54,640 2 @ 1 2 24 5250 3990 7540 210
E96162#00HE 96 # 16000 54,640 2 @ 1 2 24 5250 3890 8400 268
E108243#00HE 108 # 24000 81,960 3 @ 1 3 24 5250 4200 10200 291
E120243#00HE 120 # 24000 81,960 3 @ 1 3 24 5250 4075 10940 304
E132243#00HE 132 # 24000 81,960 3 @ 1 3 24 5250 3975 11800 317
E144243#00HE 144 # 24000 81,960 3 @ 1 3 24 5250 3890 12600 330
E42121#00HE 42 # 12000 40,980 1 @ 1 1 24 5250 3990 3770 109
E48121#00HE 48 # 12000 40,980 1 @ 1 1 24 5250 3890 4200 116
E60121#00HE 60 # 12000 40,980 1 @ 1 1 24 5250 3675 4960 132
E72242#00HE 72 # 24000 40,980 2 @ 1 2 24 5250 4200 6800 197
E84242#00HE 84 # 24000 81,960 2 @ 1 2 24 5250 3990 7540 210
E96242#00HE 96 # 24000 81,960 2 @ 1 2 24 5250 3890 8400 268
E108363#00HE 108 # 36000 81,960 3 @ 1 3 24 5250 4200 10200 291
E120363#00HE 120 # 36000 122,940 3 @ 1 3 24 5250 4075 10940 304
E132363#00HE 132 # 36000 122,940 3 @ 1 3 24 5250 3975 11800 317
E144363#00HE 144 # 36000 122,940 3 @ 1 3 24 5250 3890 12600 330
E42161#00HE 42 # 16000 122,940 1 @ 1 1 24 5250 3990 3770 109
E48161#00HE 48 # 16000 54,640 1 @ 1 1 24 5250 3890 4200 116
E60161#00HE 60 # 16000 54,640 1 @ 1 1 24 5250 3675 4960 132
E72322#00HE 72 # 32000 54,640 2 @ 1 2 24 5250 4200 6800 197
E84322#00HE 84 # 32000 54,640 2 @ 1 2 24 5250 3990 7540 210
E96322#00HE 96 # 32000 109,280 2 @ 1 2 24 5250 3890 8400 268
E108483#00HE 108 # 48000 109,280 3 @ 1 3 24 5250 4200 10200 291
E120483#00HE 120 # 48000 109,280 3 @ 1 3 24 5250 4075 10940 304
E132483#00HE 132 # 48000 163,920 3 @ 1 3 24 5250 3975 11800 317
E144483#00HE 144 # 48000 163,920 3 @ 1 3 24 5250 3890 12600 330
# - INDICATE VOLTAGE: 3 = 208V 3-PH, 4 = 240V/208V 3-PH, 5 = 480V 3-PH.
Note: Multiply listed wattage by .75 for actual 208V rating. Maximum
15 kilowatts per cabinet at 240V.
3/4 HP Models
E42081#30HE 42 # 8000 27,320 1 @ 3 1 24 7200 4760 4495 117
E48081#30HE 48 # 8000 27,320 1 @ 3 1 24 7200 4615 4980 125
E60081#30HE 60 # 8000 27,320 1 @ 3 1 24 7200 4320 5830 141
E72162#30HE 72 # 16000 54,640 2 @ 3 2 24 7200 5040 8160 211
E84162#30HE 84 # 16000 54,640 2 @ 3 2 24 7200 4760 8990 226
E96162#30HE 96 # 16000 54,640 2 @ 3 2 24 7200 4615 9960 241
E108243#30HE 108 # 24000 81,960 3 @ 3 3 24 7200 5040 12240 312
E120243#30HE 120 # 24000 81,960 3 @ 3 3 24 7200 4870 13070 327
E132243#30HE 132 # 24000 81,960 3 @ 3 3 24 7200 4730 14040 342
E144243#30HE 144 # 24000 81,960 3 @ 3 3 24 7200 4615 14940 357
E42121#30HE 42 # 12000 40,980 1 @ 3 1 24 7200 4760 4495 117
E48121#30HE 48 # 12000 40,980 1 @ 3 1 24 7200 4615 4980 125
E60121#30HE 60 # 12000 40,980 1 @ 3 1 24 7200 4320 5830 141
E72242#30HE 72 # 24000 40,980 2 @ 3 2 24 7200 5040 8160 211
E84242#30HE 84 # 24000 81,960 2 @ 3 2 24 7200 4760 8990 226
E96242#30HE 96 # 24000 81,960 2 @ 3 2 24 7200 4615 9960 241
E108363#30HE 108 # 36000 81,960 3 @ 3 3 24 7200 5040 12240 312
E120363#30HE 120 # 36000 122,940 3 @ 3 3 24 7200 4870 13070 327
E132363#30HE 132 # 36000 122,940 3 @ 3 3 24 7200 4730 14040 342
E144363#30HE 144 # 36000 122,940 3 @ 3 3 24 7200 4615 14940 357
E42161#30HE 42 # 16000 122,940 1 @ 3 1 24 7200 4760 4495 117
E48161#30HE 48 # 16000 54,640 1 @ 3 1 24 7200 4615 4980 125
E60161#30HE 60 # 16000 54,640 1 @ 3 1 24 7200 4320 5830 141
E72322#30HE 72 # 32000 54,640 2 @ 3 2 24 7200 5040 8160 211
E84322#30HE 84 # 32000 54,640 2 @ 3 2 24 7200 4760 8990 226
E96322#30HE 96 # 32000 109,280 2 @ 3 2 24 7200 4615 9960 241
E108483#30HE 108 # 48000 109,280 3 @ 3 3 24 7200 5040 12240 312
E120483#30HE 120 # 48000 109,280 3 @ 3 3 24 7200 4870 13070 327
E132483#30HE 132 # 48000 163,920 3 @ 3 3 24 7200 4730 14040 342
E144483#30HE 144 # 48000 163,920 3 @ 3 3 24 7200 4615 14940 357
# - INDICATE VOLTAGE: 3 = 208V 3-PH, 4 = 240V/208V 3-PH, 5 = 480V 3-PH.
Note: Multiply listed wattage by .75 for actual 208V rating. Maximum
15 kilowatts per cabinet at 240V.
