32
Stability bracket
We recommend a stability bracket is fitted to the cooker.
The type shown in fig. 34 can be purchased from most plumbers merchants and
do it yourself (D.I.Y.) shops.
Wall fixing Floor fixing
Brackets
Existing slot in
rear of cooker
Dotted line showing the
position of cooker when fixed
Dimension is in millimetres
3
Outline of cooker
backplate at the
engagement slot
Fig. 34
