Installing the 9Cx14 Chassis

Figure 1-3. Installing a Power Supply

100-125v-12A

200-250v-6A

50-60 Hz

POWER SUPPLY MODULE

9C214-1

100%

50%

0%

STATUS

P

W
R

S
N
B

Load

Securing
Screw

Tab

Securing

Screw

Slot on

Chassis
