15
TRANSMITTER PROGRAMMING
Note: All transmitter codes must be learned at time of programming!! The unit will learns up to 4 different
transmitter codes.
1. Open Hood (If no hood pin installed with your system, then you must ground the Gray Hood pin wire).
2. Turn key to the ON position.
3. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times.
4. Press button #1 & #2 together of the transmitter to be coded. You should get 2 light flashes indicating the unit is
waiting for a 2 nd code, then press button #1 & #2 of a second transmitter, the unit will flash 3 times indicating its
waiting for the 3 rd code and so on. If all 4 codes are learned, the unit will automatically exit code learning mode,
otherwise turn key off and close hood. See diagram below.
IGN
OFF
WAIT FOR
4 FLASHES
PRESS 4X's
FLASH 2, 3, or 4 X's
(GRAY WIRE GROUNDED)
IGN
OFF
1-WAY
START
COOLSTART
PRESS TOGETHER
