Back View

WARNING:

Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow

environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer
turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.

12

11

9

4

3

1

1

modem connector (optional)

2

network connector

3

power and battery status lights

4

video connector (VGA)

5

AC adapter connector

6

security cable slot

7

eSATA/USB 2.0 connector

8

USB 2.0 connector

9

multimode DisplayPort connector

10

cooling vent

11

ExpressCard slot

12

Secure Digital (SD) and MMC card slot

10

2

5

6 7

8
