Side View
Bottom View
Label Description Use
1 Barcode serial number label To contact Dell for technical support.
2 Security lock slot To help secure your monitor.
3 Regulatory rating label Lists the regulatory approvals.
4 Dell Soundbar mounting brackets To attach the optional Dell Soundbar.
Right view left view
Bottom view
Label Description
1 AC power cord connector
2 HDMI connector
3 VGA connector
Monitor Specifications
The following sections give you information about the various power management modes and pin assignments for various connectors for your monitor.
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type TN
