Dell Latitude E4310 (Mid 2010) - Manual

Setup and Features Information
Front View
3
4
5
6
7
8
1 ambient-light sensor
2 camera (optional)
3 camera-status light (optional)
4 display
5 microphone (optional)
6 Dell Latitude ON™ button (optional)
7 power button
8 video connector (VGA)
9 USB 2.0 connector
10 optical drive
11 volume-control buttons (3)
12 wireless switch
13 ExpressCard slot
14 fingerprint reader (optional)
15 contactless smart-card reader (optional)
16 memory-card slot
17 touchpad buttons (2)
18 touchpad
19 track-stick buttons (3)
20 track stick
21 keyboard
22 device-status lights
23 microphone
1
2
9
10
11
12
13 14
17
16
20
15
19
18
21
23
22
NOTE: Your computer ships with the optional
microphone only if you order the camera.
Regulatory Model: P05G Regulatory Type: P05G001
Dell ™ Latitude ™ E4310 About Warnings
WARNING: A WARNING indicates a potential for
property damage, personal injury, or death.
June 2010
