Storage Enclosures
Storage Enclosure FW Revision Number of Enclosures Supported
MD1200 SAS 1.0.1 or later Four (4)
Compellent (Fiber Channel) All Up to 80TB
MD3600f Up to 80TB
NOTE: To connect or disconnect the redundant SAS cable(s), the DL4000 system must be powered off. One cable may be unplugged
while the server is running. Do not disconnect both cables while the server is running or the external array disk will later be
rediscovered as foreign disks.
Hard Drives (External)
Storage Enclosure RAID Controller Drive Type Drive Capacity
MD1200 PERC H810 Nearline SAS 1TB , 2TB, 3TB, 4TB (High Capacity)
Network Interface Controllers (NIC)
System NIC Driver Revision
DL4000 (All Capacities) Broadcom 57800S Quad-Port 1GbE NDC 16.2.0.4 or later
DL4000 Standard Capacity Intel I350 Quad-Port 10GbE NIC [Low Profile
Bracket]
12.0.150.0 or later
DL4000 High Capacity Broadcom BCM57810 10GbE NIC [Low Profile
Bracket]
16.2.0.4 or later
Fiber Channel Controllers
System HBA Driver Revision
DL4000 High Capacity only Qlogic QLE 2562 9.1.11.28 or
later
Emulex LPE 12002 2.72.205.4 or
later
