Dell Precision M6400 (Late 2008) - Manual (Page 2)

Back View
1 display latches (2) 2 microphones (2)
3 camera (optional) 4 display
5 fingerprint swipe/FIPS reader 6 power button
7 USB 2.0 connector 8 USB2.0/eSATA connector
9 VGA connector 10 DisplayPort
11 network connector 12 ExpressCard slot
13 Wi-Fi Catcher™ 14 wireless switch
15 keyboard 16 wireless smart card reader
17 display release latch 18 touch pad buttons (3)
19 touch pad 20 track stick buttons (3)
21 track stick 22 keyboard status lights
23 device status lights 24 speakers (2)
1
3
7
6
8
2
4
5
9
10
