34 Removing and Replacing Parts
w
w
w
.d
e
ll
.co
m
|
s
u
p
p
o
rt
.d
e
ll.c
o
m
Removing the 12.1-Inch Display Assembly Bezel
NOTICE: Disconnect the computer and any attached devices from electrical
outlets, and remove any installed batteries.
NOTICE: To avoid ESD, ground yourself by using a wrist grounding strap or
by touching an unpainted metal surface on the computer.
NOTICE: Read "Preparing to Work Inside the Computer" before performing
the following procedure.
1 Remove the hard drive.
2 Remove the display assembly.
3 Use the scribe to pry the six rubber screw covers out of the screw holes
located on the bezel on the front of the display assembly.
4 Remove the six M2.5 x 5-mm screws located on the bezel on the front
of the display assembly.
NOTICE: To avoid damage to the bezel, do not bend the bezel while
separating it from the display-assembly top cover.
5 Use a plastic scribe to carefully separate the bezel from the
display-assembly top cover.
Removing the 12.1-Inch Display Panel
NOTICE: Disconnect the computer and any attached devices from electrical
outlets, and remove any installed batteries.
NOTICE: To avoid ESD, ground yourself by using a wrist grounding strap or
by touching an unpainted metal surface on the computer.
1 Remove the hard drive.
2 Remove the display assembly.
3 Remove the display assembly bezel.
4 Remove the hinge covers.
5 Remove the four M3 x 3-mm screws on the front of the display panel
that secure the display panel to the support bracket.
6 Remove the M2 x 4-mm screw that secures the display-feed flex cable
to the display assembly through the black plastic flex cable retention
bracket (see "12.1-Inch Display Assembly Bezel and Panel").
