Item Non-Volatile
or Volatile Quantity Reference Designator Size
ONFI Backup Flash Non-volatile 1 U4 4GB
SDRAM Volatile 5 U1043-U1047 512MB/1GB
NVRAM (WAM 2) Card
DDR3 SODIMM Volatile 1 J1 8GB
NAND Flash Non-Volatile 1 U10, U11, U17, U18 64Gbit
Boot Flash (NOR) Non-Volatile 1 U12 8MB
EEPROM Non-Volatile 1 U46 2Kbit
Monet Serial Flash Non-Volatile 1 U21 16Mbit
Monet DDR Volatile 1 U13 2Gb
NVSRAM Flash Non-Volatile 1 U1 1Mbit
NVRAM (WAM 1)
Card
DDR2 RDIMM Volatile 1 J1 8 GB
NAND Flash Non-Volatile 4 U56, U57, U58, U59 32 GB
Boot Flash (NOR) Non-Volatile 1 U9 8 MB
EEPROM Non-Volatile 1 U2 2K bit
Van Gogh Serial Flash Non-Volatile 1 U47 4Mb
Van Gogh DDR2 Volatile 1 U45 128 Mb
NVSRAM Flash Non-Volatile 1 U7 1 Mbit
Item Type (e.g. Flash PROM, EEPROM) Can user programs or operating
system write data to it during normal
operation?
Planer
PCH Internal CMOS RAM Battery-backed CMOS RAM No
BIOS SPI Flash SPI Flash No
iDRAC SPI Flash SPI Flash No
BMC EMMC eMMC NAND Flash No
CPU Vcore and VSA
Regulators OTP(one time programmable) No
System CPLD RAM RAM No
System Memory RAM Yes
