Repeat steps 2 to 5 for all tiered switches you wish to attach to your system.
To connect local peripherals:
1
Select the keyboard, monitor and mouse to be connected to local user A.
2
Locate the port set labeled A on the back of the appliance. Connect these peripherals to their
respective ports.
NOTE: For the multiuser, 16-port Console Switch, repeat these steps for the local analog port set labeled
B.
3
Bundle and label the cables for easy identification.
Setting Up Your Console Switch System
With the Console Switch system, you can auto detect and configure each port on your appliance.
"Basic Operation" provides detailed instructions on naming, customization, and OSCAR interface
setup and configuration.
