Dell Latitude XT2 (Early 2009) - Manual (Page 6)

Specifications
NOTE:
Offerings may vary by region. For more information regarding the configuration of
your computer, click Start→ Help and Support and select the option to view information
about your computer.
Video
Video type: integrated on system board, hardware accelerated
Data bus integrated video
Video controller Intel
®
Integrated "Cantiga" UMA Graphics
Video memory up to 256 MB shared video memory
Battery
Type 4-cell "smart" lithium ion (28 WHr)
6-cell "smart" lithium ion (42 WHr)
Dimensions:
Depth 96.84 mm (3.81 inches)
Height 13.7 mm (0.54 inch)
Weight 0.26 kg (0.57 lb) (4 cell)
0.34 kg (0.74 lb) (6 cell)
Voltage 11.1 VDC
Temperature range:
Operating 0° to 35°C (32° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Coin-cell battery CR-2025
AC Adapter
Input voltage 100–240 VAC
Input current (maximum) 1.5 A
Input frequency 50–60 Hz
Output current 2.31 A
2.34 A (optional)
4.62 A (optional)
