Dell Vostro 1720 (Early 2009) - Manual (Page 3)

Vostro 1520
1 microphone (optional) 2 camera light (optional)
3 camera (optional) 4 media controls (volume, forward,
reverse, stop, play, and mute)
5 security cable slot 6 optical drive/media bay
7 fingerprint reader (optional) 8 USB connectors (2)
9 IEEE 1394 connector 10 contactless smart card reader (available
in Japan only)
11 touch pad 12 touch pad buttons (2)
13 8-in-1 card reader slot 14 audio connectors (2)
