Dell Powered USB Hub - Manual

4 Connect AC power cord to hub and power outlet
Setting Up Your Powered USB Hub
CAUTION:
Before you set up and operate your Dell hub, see the
safety instructions in the Product Information Guide
TM
www.dell.com
|
support.dell.com Continued Dell Host PC and Integrator sold separately 1 -
0TF663A00
*0TF663A00*
1 Unpack your Powered USB Hub
1. Port LEDs (6)
2. Status LED
3. Host LED
4. Service Tag Label
1 2 3
This placemat is only intended for quick reference.
Consult your Product Information Guide for complete details
2 If Integrator is used, remove cover from Integrator (a)
and slide tray out (b) 1
(b)
(a)
3 If Integrator is used, install retainers (a) and hub (b)
NOTE: If Integrator is not used, place hub in secured
position
(b)
(a)
4
5
1. USB Peripheral Ports (+12 V) (5)
2. USB Peripheral Port (+24 V)
3. USB Host Port
4. Power Switch
5. AC Power Port
6. AC Pass-Through Power Ports (2)
1 2
3
6
4
