Dell Latitude E6400 ATG (Mid 2008) - Manual (Page 56)

1. Follow the procedures in Working on Your Computer .
2. Turn your computer upside down.
3. If your computer has a security screw for the modular drive, remove the security screw.
4. Push the release latch in to release it.
5. Use the release latch to slide the drive out of the modular bay.
6. Remove the M2.5 x 5-mm screw that holds the release latch in place.
7. Slide the release latch out from the release latch carrier.
8. Remove the M2.5 x 5-mm screw that holds the carrier for the release latch in place.
9. Slide the release latch carrier out of the hard drive carrier.
NOTICE: To prevent data loss, turn off your computer before removing the hard drive. Do not remove the hard drive while the computer is on or in
Sleep state.
NOTICE: Hard drives are extremely fragile. Exercise care when handling the hard drive.
1 security screw 2 modular bay
3 modular drive 4 release latch
1 release latch 2 release latch carrier
3 M2.5 x 5-mm screw
