2 When HyperTerminal prompts for a name, type
MD3000 or MD3000i and
click OK. Select the COM1 port and click OK.
3 Set the following communication settings, click Apply, then click OK.
Bits per second: 115200
Data bits: 8
Parity: none
Stop bits: 1
Flow control: none
LINUX Operating System
The following instructions use the Linux application, MINICOM, to connect via
the serial port:
1 Open a terminal/command window.
2 At the prompt, type
minicom (all lowercase) and press .
3 Once MINICOM is open, press , then , then the letter
to open the configuration screen.
4 Select Serial Port Setup and press .
5 Press to change Hardware Flow Control setting to
no .
6 Press to set the Comm Parameters.
7 Press to set the
speed to 115200 .
8
P ress to set the data , parity , and stopbits to 8-N-1 ,
then press .
9 Press to exit the Comm Parameters screen.
10 Select Exit and press again to exit the setup screen.
Reset Password
The procedure you should use to reset the password depends on whether your
RAID controller is running first-generation firmware (version 06.
xx.xx.xx) or
second-generation firmware (version 07. xx.xx.xx).
