Dell Studio Desktop D540 (Late 2008) - Manual (Page 52)

50
Specifications
System Board Connectors
PCI Express x16
one 164‑pin
connector
Power one 24‑pin connector
Power 12 V one 4‑pin connector
Processor 775 pin
Processor fan one 4‑pin connector
Serial ATA four 7‑pin connectors
Physical
Height
362 mm (14.2 inches)
Width 170 mm (6.7 inches)
Depth 435 mm (17.1 inches)
Weight 12.5 kg (28.0 lb)
External connectors
Video
one VGA and one
HDMI connector
Network adapter RJ45 connector
USB two front‑panel and
four back‑panel
USB 2.0 compliant
connectors
Audio six connectors for 7.1
support
S/PDIF one S/PDIF connector
IEEE one front‑panel and
one back‑panel 6‑pin
serial connector
