Dell Vostro V13 (Late 2009) User Manual
Page 2
Back View
WARNING:
Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer
turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.
5
4
3
2
1
network connector
2
eSATA/USB connector
3
USB connector
4
video connector
5
AC adapter connector
6
cooling vent
7
security cable slot
6
7
1
YK2KYcc0.fm Page 2 Wednesday, October 28, 2009 1:30 PM
