463821908 • 11
Certified Grill Parts And Accessories®, Char-Broil and Design®, Char-Broil (Gas Grill Briquettes)®, Char-Diamonds®, Cooking Zone and Design®, Diamond Flame®, Executive Chef®, Faststart®, Flare
Fighter®, FlavorMaster®, Gas Grill Silouette and Design®, H2O Smoker®, Lava Flame®, MasterFlame®, MasterFlame Precision Cooking System®, PowerSpark®, Quantum®, VIP®, PrecisionFlame and
Design®, Sierra®, and TruFlame® are registered Trademarks of the W.C. Bradley Company. Thermos® is a registered trademark of the Thermos Company and its affiliates.
Artisan Collection by Char-Broil ™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™,
Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™, The Minute Grill™, The Edge™, The Tuscan
Collection™, and The Urban Grill™ are Trademarks of the W.C. Bradley Company. Universal Grill Parts and Design™ is a trademark of the Thermos Company and its affiliates.
Protected under one or more of the following U.S. Patents: 4,598,692; 4,624,240; 4,747,391; 4,747,391; 4,817,583; 4,924,846; 4,989,579; 5,003,960; 5,076,256; 5,076,257; 5,090,398; 5,109,834; 5,224,676;
5,277,106; 5,421,319; 5,441,226; 5,452,707; 5,458,309; 5,566,606; 5,566,606; 5,579,755; 5,582,094; 5,613,486; 5,649,475; 5,706,797; 5,711,663; 5,765,543; 5,931,149; 5,996,573; 6,095,132; 6,135,104;
6,173,644B1; 6,279,566; 6,397,731; 6,418,923; 6,439,222; 6,523,461; 6,935,327; D282,619; D339,714; D341,292; D343,337; D358,059; D361,466; D364,535; D372,637; D373,701; D377,735; D383,035;
D397,910; D405,643; D405,643; D406,005; D406,009; D413,043; D413,229; D413,229; D414,982; D415,388; D416,164; D416,441; D416,441; D417,587; D422,516; D423,274; D423,876; D428,303; D435,396;
D436,004; D438,059; D438,060; D438,427; D439,110; D442,505; D443,179; D443,354; D447,384; D447,385; D447,909; D448,610; D448,614; D448,615; D448,616; D448,975; D449,492; D451,759; D456,202S;
D460,313, D461,359 and D504,048. Canada: 87743; 87744; 92607; 92608 and 1,316,424. Other Patents Pending. Assembly instructions © 2006.
PARTS LIST – Model No. 463821908
Key Qty Description . . . . . . . . . . . . . . . . . . . Part #
A 1 Firebox. . . . . . . . . . . . . . . . . . . . . 80011600
B 1 Valve/Hose/Regulator . . . . . . . . . 80016425
C 1 Control Panel . . . . . . . . . . . . . . . . 80016558
D 2 Control Knobs . . . . . . . . . . . . . . . 80008245
E 1 Ignitor. . . . . . . . . . . . . . . . . . . . . . 5156113
F 2 Axle F/Wheel . . . . . . . . . . . . . . . . 80011619
G 1 Left Cart Assy w/match holder . . . 80011604
H 1 Burner Assembly . . . . . . . . . . . . . 80011601
I 2 Wheels. . . . . . . . . . . . . . . . . . . . . 80008000
J 1 Right Cart Leg . . . . . . . . . . . . . . . 80011605
K 2 Leg Extenders . . . . . . . . . . . . . . . 80008291
L 1 Bottom Shelf . . . . . . . . . . . . . . . . 80011606
M 1 Back Support Brace. . . . . . . . . . . 80011607
N 1 Tank Retainer. . . . . . . . . . . . . . . . 80008294
O 1 Front Panel . . . . . . . . . . . . . . . . . 80011608
P 1 Side Shelf . . . . . . . . . . . . . . . . . . 80011609
Q 1 Lid . . . . . . . . . . . . . . . . . . . . . . . . 80011610
R 1 Logo Plate Assembly . . . . . . . . . . 80011611
S 1 Handle Assembly . . . . . . . . . . . . . 80011612
T 1 Sideburner Frame . . . . . . . . . . . . 80011613
U 1 Sideburner Pan . . . . . . . . . . . . . . 80011614
V 1 Sideburner Grate . . . . . . . . . . . . . 80010163
W 1 Tool Holder. . . . . . . . . . . . . . . . . . 80011615
X 1 Sideburner Valve Cup . . . . . . . . . 80011616
Y 1 Sideburner . . . . . . . . . . . . . . . . . . 80016559
Z 1 Sideburner Knob . . . . . . . . . . . . . 80010161
Key Qty Description . . . . . . . . . . . . . . . . . . . Part #
AA 1 Heat Tent . . . . . . . . . . . . . . . . . . . 80008273
BB 1 Cooking Grate . . . . . . . . . . . . . . . 80008274
CC 1 Swing Away . . . . . . . . . . . . . . . . . 80008275
DD 2 Lower Hinge. . . . . . . . . . . . . . . . . 80011618
EE 2 Upper Hinge. . . . . . . . . . . . . . . . . 80011617
FF 1 Grease Cup . . . . . . . . . . . . . . . . . 80000270
GG 1 Clip, Grease Cup . . . . . . . . . . . . . 80000271
HH 1 Heat Shield F/Tank . . . . . . . . . . . 80016679
II 1 Heat Shield F/Firebox . . . . . . . . . 80016680
1 Product Manual, English . . . . . . . 80016556
1 Hardware Pack . . . . . . . . . . . . . . 80009105
1 Venturi Clip
2 Axle Bolt
6 Wing Nut, Plastic
7 #10-24x2" Carriage Bolt
4 Hitch Pin
22 #10-24 Flange Nut
28 Silicone Washer
4 #10-24x1-1/4" Machine Screw
3 #10-24 Wing Nut, Metal
5 #10-24 T-Wing Screw
6 #10-24x2" Machine Screw
16 #10-24x1/2" Machine Screw
2 Insulation Washer
2 Hinge Pin
