Battery, Power adapter – Dell Inspiron 14 (5439, Late 2013) User Manual

Page 5

background image

Battery

Type

3 cell

Dimensions:

Width

7.81 in (198.5 mm)

Depth

0.30 in (7.5 mm)

Height

3.91 in (99.5 mm)

Weight (maximum)

0.60 lb (269 g)

Voltage

11.4 VDC

Operating time

Varies depending on operating conditions and
can significantly reduce under certain power‑
intensive conditions.

Life span (approximate)

300 discharge/charge cycles

Temperature range:

Operating

0 °C to 50 °C (32 °F to 122 °F)

Storage

0 °C to 65 °C (32 °F to 149 °F)

Coin‑cell battery

LI 3V 83 MAH

Power Adapter

Type

• 65 W
• 90 W

Input voltage

90 VAC–264 VAC

Input frequency

50 Hz–60 Hz

Input current:

65 W

1.50 A (maximum)

90 W

1.60 A (maximum)

Output current:

65 W

3.34 A

90 W

4.62 A

Rated output voltage

19.50 VDC

Temperature range:

Operating

0 °C to 40 °C (32 °F to 104 °F)

Storage

–40 °C to 70 °C (–40 °F to 158 °F)
