Replacing the power-light board, Postrequisites – Dell XPS 13 (L321X, Early 2012) User Manual
Page 16
16
Power-Light Board
Replacing the Power-Light Board
1 Align the screw hole on the power-light board with the screw hole on
the palm-rest assembly.
2 Replace the screw that secures the power-light board to the
palm-rest assembly.
3 Slide the power-light board cable into the system-board connector
and press down on the connector latch to secure the cable.
Postrequisites
1 Replace the base cover. See "Replacing the Base Cover" on page 14.
2 Follow the instructions in "After Working Inside Your Computer" on page 11.
OM_Book.book Page 16 Tuesday, September 25, 2012 2:30 PM
