Dell Precision T5500 (Early 2009) - Manual (Page 44)

Memory and Memory Shroud
Dell Precision™ T5500 Service Manual
Your computer features an optional dual-processor riser to accommodate dual processor and expanded memory options (see Dual Processor Riser (Optional) ).
Memory modules are removed from and installed into slots both on the system board or on the optional dual-processor riser identically, although only the slots
located on the system board are illustrated below.
Removing the Memory Shroud and Memory Modules
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the computer cover .
3. Lift the hard drive tray .
4. Lift the memory shroud straight up and remove the memory shroud from the computer.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
