Back View
1 microphone (optional) 2 camera light (optional)
3 camera (optional) 4 display
5 media controls (volume, forward,
reverse, stop, play, and mute) 6 power button
7 security slot 8 optical device in media bay
9 USB connectors (2) 10 fingerprint reader (optional)
11 audio connectors (2) 12 power and battery charge status lights
13 wireless switch 14 speaker
15 touch pad buttons (2) 16 touch pad
17 keyboard 18 device status lights
19 keyboard status lights
1 ExpressCard slot 2 SD card reader slot
3 USB connector 4 network connector
5 VGA connector 6 cooling vents
7 phone connector 8 AC adapter connector
8
6
5
7
4
2
1
3
