Dell S1909WN Monitor - Manual (Page 5)

Bottom view
Label Description
1 AC power cord connector
2 VGA connector
Monitor Specifications
Flat Panel Specifications
*[S1909WN] color gamut (typical) is based on CIE1976 (85%) and CIE1931 (72%) test standards.
Screen type Active matrix - TFT LCD
Panel type TN
Screen dimensions
18.5 inches (18.5-inch viewable
image size)
Preset display area: 409.8(H)X230.4(V)
Horizontal 409.8 mm (16.13 inches)
Vertical 230.4 mm (9.07 inches)
Pixel pitch 0.3 mm
Viewing angle
160° (vertical) typical, 170°
(horizontal) typical
Luminance output 300 CD/m²(typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Antiglare with hard-coating 3H
Backlight CCFL (2) edgelight system
Response Time 5 ms typical
Color Depth 16.7 mil colors
Color Gamut 85%*
