SCSI channels Two 68-pin U320 SCSI
Video
Video type ATI Radeon 7000-M video controller; VGA connectors
Video memory 16 MB
Power
AC power supply (per power supply)
Wattage 930 W
Voltage 85–264 VAC, autoranging, 47–63 Hz, 13.32 A
Heat dissipation 2697 BTU/hr maximum
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 25 A per power supply for 10 ms or less.
Batteries
System battery CR 2032 3.0-V lithium ion coin cell
ROMB battery (optional) 4.1-V lithium ion
Physical
Rack
Height 21.79 cm (8.580 in)
Width 48.03 cm (18.908 in)
Depth 71.13 cm (28.002 in)
Weight (maximum configuration) 45.36 kg (100 lb)
Tower (without bezel)
Height 48.55 cm (19.113 in)
Width 30.15 cm (11.869 in)
Depth 69.58 cm (27.392 in)
Weight (maximum configuration) 48.98 kg (108 lb)
Environmental
NOTE: For additional information about environmental measurements for specific system configurations, see
www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 8% to 85% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.25 G at 3–200 Hz for 15 min
Storage 0.5 G at 3–200 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis (one pulse on
each side of the system) of 41 G for up to 2 ms
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
Altitude
Operating – 16 to 3048 m (–50 to 10,000 ft)
Storage – 16 to 10,600 m (–50 to 35,000 ft)
