Technical Specifications
NOTE: The following specifications are only those required by law to ship with your system. For a complete and
current listing of the specifications for your system, go to support.dell.com.
Power
AC Power Supply (per power supply)
Wattage 717 W
Heat dissipation
NOTE: Heat dissipation is calculated using the
power supply wattage rating. The heat
dissipation values are for the entire system
which includes (chassis and two controllers).
2446.8 BTU/hr
Voltage
NOTE: This system is also designed to be
connected to IT power systems with a phase to
phase voltage not exceeding 230 V.
90 V AC to 264 V AC, autoranging, 47 Hz/63 Hz
Battery
Storage controller backup power supply 12.8 V to 13.2 V, 4.8 Ah to 6 Ah, 63 Wh to 77 Wh
Physical
Height 86.40 mm (3.40 inch)
Width 481.50 mm (18.96 inch) with rack latches
446.30 mm (17.57 inch) without rack latches
Depth 741.0 mm (29.21 inch) without bezel and handle
813.10 mm (32.01 inch) with bezel and handle
Weight (maximum configuration) 30.50 kg (67.0 lb)
Weight (empty) 12.86 kg (28.36 lb)
Environmental
NOTE: For additional information about environmental measurements for specific system configurations, see
dell.com/environmental_datasheets.
Temperature
Operating Continuous operation: 5 °C to 40 °C (41 °F to 104 °F) with a
maximum temperature gradation of 20 °C per hour
Storage –40 °C to 60 °C (–40 °F to 140 °F) with a maximum temperature
gradation of 20 °C per hour
Relative humidity
