Externally accessible:
Serial 9-pin connector; 16550C-compatible
Parallel 25-hole connector (bidirectional)
Video 15-hole connector
Keyboard 6-pin mini-DIN connector or USB connector
Mouse 6-pin mini-DIN connector or USB connector
USB two front-panel and two back-panel USB–compliant
connectors
Headphone front-panel miniature connector
Audio 2 three miniature connectors for line in, line out, and
microphone
Internally accessible:
Primary IDE channel 40-pin connector on PCI local bus
Secondary IDE channel 40-pin connector on PCI local bus
Floppy drive 34-pin connector
2 Present only on computers with built-in audio capabilities.
Audio 3
Audio controller Analog Devices AD1885 AC97 Codec
3 Present only on computers with built-in audio capabilities.
Video
Video controller AGP 4X
Controls and Lights
Power control push button
Power light green light on power button—blinking green in sleep
state; solid green for power on state
Hard-drive access light green
Diagnostic code lights four bicolor (amber and green) located on back panel
Power
DC power supply:
Wattage 180 W
Heat dissipation 500 BTU (fully-loaded computer without monitor)
Voltage (see " Safety Instructions " for
important voltage setting information)
90 to 135 V at 50/60 Hz; 180 to 265 V at 50/60 Hz;
100 V at 50/60 Hz for Japanese computers
Backup battery 3-V CR2032 coin cell
Physical
Height x Width x Depth 10.6 x 38.9 x 43.2 cm
(4.2 x 15.3 x 17 inches)
Weight 9.9 kg (22 lb)
Environmental
Temperature:
Operating 10º to 35ºC (50º to 95ºF) 4
Storage – 40º to 65ºC (–40º to 149ºF)
Relative humidity 20% to 80% (noncondensing)
Maximum vibration:
Operating 0.25 G at 3 to 200 Hz at 1/2 octave/min
Storage 0.5 G at 3 to 200 Hz at 1/2 octave/min
Maximum shock:
Operating bottom half-sine pulse with a change in velocity of
50.8 cm/sec (20 inches/sec)
Storage 23-G faired-square wave with a velocity change of
508 cm/sec (200 inches/sec)
Altitude:
Operating – 15.2 to 3048 m (–50 to 10,000 ft) 4
