Removing the System Board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before Working Inside Your Computer . After working inside your
computer, follow the instructions in After Working Inside Your
Computer . For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
NOTE: Your computer’s Service Tag is stored in the system board. You
must enter the Service Tag in the system setup after you replace the
system board.
NOTE: Replacing the system board removes any changes you have
made to the BIOS using System Setup. You must make the desired
changes again after you replace the system board.
NOTE: Before disconnecting the cables from the system board, note the
location of the connectors so that you can reconnect them correctly
after you replace the system board.
Prerequisites
1 Remove the battery .
2 Remove the optical drive .
3 Remove the base cover .
4 Remove the memory module(s) .
5 Remove the wireless card .
6 Remove the hard drive .
7 Remove the keyboard .
8 Remove the palm rest .
Procedure
1 Peel the tape that secures the display cable to the connector on the
system board.
2 Lift the latch and, using the pull-tab, disconnect the display cable from
the connector on the system board.
3 Peel the display cable from the fan.
4 Lift the latch and, using the pull-tab, disconnect the I/O-board cable
from the connector on the system board.
