Dell Studio 1537 (Late 2008) - Manual (Page 63)

61
Basic Specifi cations
Ports and Connectors
eSATA one seven-pin/four-
pin eSATA/USB combo
connector
USB four 4-pin USB 2.0-compliant
connectors
Video 15-hole connector
HDMI 19 pin
Display
Type (TrueLife) 15.4-inch WLED WXGA TL
15.4-inch WLED WXGA+ TL
15.4-inch CCFL WUGA TL
Dimensions:
Height 207 mm (8.14 in)
Width 331.2 mm (13.03 in)
Display
Diagonal 391.2 mm (15.4 in)
Maximum resolution
WXGA with
TrueLife 1280 x 800
WXGA+ with
TrueLife 1440 x 900 at 262 K colors
WUXGA with
TrueLife 1600 x 1200 at 262 K colors
Refresh rate 60 Hz
Operating
angle 0° (closed) to 140°
Viewing Angles:
Horizontal ±40° (WXGA with TrueLife)
±55° (WXGA+ with TrueLife)
±55° (WUXGA with TrueLife)
