Connecting the usb 3.0 cable – Dell UltraSharp 34 Curved Monitor User Manual
Page 32
32
| Setting
Up
the
Monitor
Connecting the USB 3.0 cable
NOTE: To prevent data damage or loss, before changing USB upstream ports, make
sure that NO USB storage devices are in use by the computer connected to the
monitor’s USB upstream port.
After you have completed connecting the Mini-DP to DP/DP/HDMI cable, follow the
procedures below to connect the USB 3.0 cable to the computer and complete your
monitor setup:
1
a. Connect one computer: connect the upstream USB 3.0 port (cable supplied) to
an appropriate USB 3.0 port on your computer.
b. Connect two computers*: connect the upstream USB 3.0 ports to appropriate
USB 3.0 ports on the two computers. Then use the OSD menu to select between
the two USB upstream sources and input sources. See
.
2
Connect the USB 3.0 peripherals to the downstream USB 3.0 ports on the monitor.
3
Plug the power cables for your computer(s) and monitor into a nearby outlet.
* When connecting two computers to the monitor, the monitor's USB downstream ports
for the keyboard and mouse can be assigned to different input signals from the two
computers by changing the USB Selection settings from the OSD menu. (See
for details).
a. Connect one computer
b. Connect two computers
